"Danfoss WVFX 40 Water Valve"
Item Number:
003F1240
| Max Operating Pressure : | 10.0 Bar |
|---|---|
| Product Group : | Pressure Reg - Danfoss |
| Refrigerant : | R22, R134a, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R448A, R449A, R449B, R450A, R452A, R454A, R454C, R455A, R507A, R513A, R515B, R516A, R1234yf |
General Information
| Model Number : | 003F1240 |
|---|---|
| Product Group : | Pressure Reg - Danfoss |
| Type : | WVFX 40 |
Additional Info
| Family : | WVFX |
|---|
Connections
| Connection Internal/External : | Internal |
|---|---|
| Connection Size : | 1 1/2 in |
| Connection Size Refrigerant : | 1/4 in, 6 mm |
| Connection Type : | G |
| Connection Type Refrigerant : | SAE flare |
Kv Values
| Kv Value : | 11.000 m³/h |
|---|
Logistical Information
| Commodity Code : | 84818059 |
|---|---|
| Country Of Origin : | POL |
| EAN : | 5702422038689 |
| Gross Weight : | 3.32 kg |
Material
| Body Material : | Cast iron |
|---|
Measurements
| Weight : | 3.20 kg |
|---|
Pressure
| Control Pressure Range : | 4.0-17.0 Bar |
|---|---|
| Differential Pressure : | 10.0 Bar |
| Max Operating Pressure : | 10.0 Bar |
| Max Pressure Drop : | 10 Bar |
Refrigerant
| Refrigerant : | R22, R134a, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R448A, R449A, R449B, R450A, R452A, R454A, R454C, R455A, R507A, R513A, R515B, R516A, R1234yf |
|---|
Standards
| Approval : | EAC, LLC CDC TYSK, PED, RoHS, RoHS China |
|---|
Temperature
| Medium Temperature Range : | -25-90 °C |
|---|
Valves
| Media : | Fresh water, Neutral brine |
|---|---|
| Opening Configuration : | Opens on rising cond. pressure |
Product information
Pressure operated water valves types WVFX and WVS are used for regulating the flow of water in refrigeration plants with water-cooled condensers. The pressure operated water valves give modulating regulation of the condensing pressure within defined limits during operation. When the refrigeration plant is stopped, the cooling water flow is shut off automatically
